Details
High image quality
Its high-quality 5 Megapixel sensor provides a high level of detail and sharpness.
It can work both during the day and in total darkness thanks to powerful infrared LEDs with a range of up to 30 meters.
Built-in microphone
Thanks to the built-in microphone, you can listen to what is happening on the scene from your smartphone.
No feeder needed
It is powered directly from the network cable (Power over Ethernet) if connected to a recorder or switch with integrated PoE.
Compatible Products
-
NV-KIT81-4CAM-5M
IP Video Surveillance KIT 8 channels 5Mpx
-
NV-KIT41-4CAM-5M
IP Video Surveillance KIT 4 channels 5Mpx
Technical specifications
| Brand | Nivian |
|---|---|
| Image sensor | 1 / 2.7 "Progressive CMOS |
| Resolution | 5 Megapixel (2592 x 1944) |
| Coding | 5MP (2592 × 1944), 4MP (2592x1520), 3MP (2048x1520), 1080P (1920x1080), 960P (1280x960), 720P (1280x720) (1 ~ 15fps) |
| Compression | H.265 / H.264 |
| Lens | 3.6 mm |
| Minimum illumination | 0 Lux / 18 SMD LEDs (30m) |
| Audio | Built-in microphone |
| Vision angle | 360º |
| Network interface | RJ-45 10 / 100M |
| Network protocol | HTTP ， UDP ， SMTP ， FTP ， DHCP ， DDNS ， NTP ， UPNP, RTSP, TCP |
| Interoperability | RTSP, WPS |
| Plug & Play access | P2P |
| Event notification | Email, FTP and video and image recording on SD card |
| Security | Password and multi-level user management |
| Internal storage | MicroSD card slot, Max 128 GB (not included) |
| Degree of protection | IPP66 |
| Feeding | DC 12V / 7W; PoE IEEE802.3af |
| Dimensions | 100.55 (ф) x 89.45 (al) mm / 300g |
Box contents
IP camera
Mounting accessories
User manual
